40T DUMP TRAILER
74,800 lbs / 34,000 kg Load Capacity
SPECIFICATIONS
| Load Capacity | 74,800 lbs / 34,000 kg |
|---|---|
| Length | 341" |
| Height | 136" |
| Max Height Tipped | 303" |
| Tongue Length | 88" |
| Width | 123" |
| Loading Height | 121" |
| Struck Volume | 585 cu ft / 16.57 m³ |
| Heaped Volume | 780 cu ft / 22.09 m³ |
| Tongue Weight | 2,300 lbs / 1,043 kg |
| Approx Weight | 26,200 lbs / 11,884 kg |
| Body Material | HARDOX™ |
| Hydraulic System | Single multi-stage (58L / 15.4 USG, slave kit: 30.6L / 6.7 USG) |
Load Capacity
74,800 lbs / 34,000 kg
Length
341"
Height
136"
Max Height Tipped
303"
Tongue Length
88"
Width
123"
Loading Height
121"
Struck Volume
585 cu ft / 16.57 m³
Heaped Volume
780 cu ft / 22.09 m³
Tongue Weight
2,300 lbs / 1,043 kg
Approx Weight
26,200 lbs / 11,884 kg
Body Material
HARDOX™
Hydraulic System
Single multi-stage (58L / 15.4 USG, slave kit: 30.6L / 6.7 USG)
FEATURES
Ready to Put a 40T to Work?
The biggest hauler in the lineup. Get a quote and dominate your next project.
